The CS 200X is a single‑rack‑space, solid‑state stereo power amplifier that delivers up to 120 W RMS per channel into 4 Ω and can be bridged for higher output. It features Peavey’s patented DDT™ compression system, selectable impedance via a rear‑panel switch, and balanced input options.
The manual covers front‑panel controls, rear‑panel connections, installation guidelines for commercial and studio environments, bridge‑mode operation, and safety instructions such as ground‑lift usage and circuit‑breaker reset procedures.
| Output Power (2 Ω, stereo) | 110 W RMS per channel |
|---|---|
| Bridge‑Mode Output (4 Ω, mono) | 220 W RMS |
| Dimensions | H 1.75" × W 19" × D 8" (4.4 × 48.3 × 20.3 cm) |
No. The selector must be changed only with the power off to avoid arcing and possible damage.
