This manual covers important safety precautions, proper handling of the power cord, battery pack charging, and usage guidelines for the camcorder, remote control, and accessories. It also explains how to avoid condensation, protect the device from magnetic fields, and maintain the unit.
Detailed sections describe the camcorder’s controls, recording steps, playback functions, and specifications such as video system, power consumption, dimensions, and battery requirements. The document ends with a specifications table and manufacturer information.
| Television system | Rotating 2-head, helical-scan system |
|---|---|
| Audio recording system | Rotating head, FM stereo system |
| Tape speed (SP mode) | Approx. 20.051 mm/sec |
| Maximum recording time (SP mode) | 90 minutes (P5-90 cassette) |
| Power consumption (recording) | 6.5 W |
| Dimensions (W × H × D) | Approx. 119 × 111 × 205 mm |
| Weight | Approx. 780 g (excluding battery pack and tape) |
| Battery pack voltage | 6 V |
Connect the supplied AC adaptor/charger to an AC outlet and attach the battery pack; the CHARGE indicator will go off when fully charged.
It flashes in the viewfinder when condensation is detected inside the camcorder or cassette.
The remote control works within a range of about 4 m (13 ft) from the sensor window on the camcorder.
Do not place heavy objects on the cord, keep it away from heat sources, and always unplug by pulling the plug, not the cord.
