AD587 is a high precision 10V reference voltage with high accuracy, low temperature drift and low static current.
The AD587 is a monolithic 10 V voltage reference that uses a laser‑trimmed buried Zener diode for high accuracy and low temperature coefficient. It offers a noise‑reduction pin and optional fine‑trim capability, making it suitable for DACs, ADCs, and other precision analog circuits.
The device is available in several 8‑lead packages (CERDIP, SOIC, PDIP) and operates from a wide supply range with a quiescent current under 4 mA. Detailed specifications, pin descriptions, and performance graphs are provided for designers.
| Output Voltage (typical) | 10.010 V |
|---|---|
| Quiescent Current | 4 mA max |
| Power Dissipation | 30 mW |
| Output Noise (0.1‑10 Hz) | < 4 µV p‑p |
The AD587 generates less than 4 µV peak‑to‑peak noise over the 0.1 Hz to 10 Hz band.
The device draws up to 4 mA of quiescent current.
The AD587 is offered in 8‑lead CERDIP, 8‑lead SOIC, and 8‑lead PDIP packages.
