The ADG506A and ADG507A are CMOS monolithic analog multiplexers with 16 channels and dual 8 channels, respectively. The ADG506A switches one of 16 inputs to a common output, depending on the state of four binary addresses and an enable input. The ADG507A switches one of eight differential inputs to a common differential output, depending on the state of three binary addresses and an enable input. Both devices have TTL and 5V CMOS logic compatible digital inputs.
The ADG506A (16‑channel) and ADG507A (8‑channel differential) are CMOS monolithic analog multiplexers designed for a wide supply range (10.8 V to 16.5 V) and extended signal capability. They feature break‑before‑make switching, low on‑resistance, and typical leakage currents of only 20 pA, making them suitable for high‑precision circuits.
Both devices are available in several packages—including 28‑lead DIP, SOIC, PLCC, TSSOP and LCCC—and operate over a commercial temperature range of –40 °C to +85 °C (industrial up to +125 °C). The datasheet provides detailed specifications, absolute maximum ratings, pin configurations, and test circuits for design verification.
| Supply Voltage Range (dual) | 10.8 V to 16.5 V |
|---|---|
| Supply Voltage Range (single) | 10.8 V to 16.5 V |
| Low Leakage Current (typical) | 20 pA |
| Power Dissipation (typical) | 10 mW |
| On‑Resistance (typical) | 280 Ω |
| Operating Temperature (commercial) | –40 °C to +85 °C |
| Available Packages | 28‑Lead DIP, SOIC, PLCC, TSSOP, LCCC |
The devices are rated for a maximum supply voltage of 44 V.
Typical leakage current is 20 pA.
They are offered in 28‑Lead DIP, SOIC, PLCC, TSSOP and LCCC packages.
Commercial versions operate from –40 °C to +85 °C; industrial versions up to +125 °C.
