The AD7760 is a 2.5 MSPS, 24-bit, 100 dB Sigma-Delta ADC with an on-chip buffer. It features a dynamic range of 120 dB and a signal-to-noise ratio of 112 dB at an output data rate of 78 kHz. The ADC is suitable for applications such as data acquisition systems, vibration analysis, and instrumentation.
The AD7760 is a 24‑bit sigma‑delta analog‑to‑digital converter that delivers high dynamic range and low noise performance. It offers up to 2.5 MSPS output data rate with programmable oversampling and an on‑chip differential amplifier for signal buffering.
The document includes functional block diagrams, pin descriptions, timing specifications, absolute maximum ratings, layout recommendations, and ordering information for the 64‑lead TQFP exposed‑pad package. It is intended for designers of high‑speed data‑acquisition systems and instrumentation.
| Dynamic Range (78 kHz ODR) | 120 dB |
|---|---|
| Dynamic Range (2.5 MHz ODR) | 100 dB |
| Signal‑to‑Noise Ratio (78 kHz ODR) | 112 dB |
| Signal‑to‑Noise Ratio (2.5 MHz ODR) | 100 dB |
| Maximum Fully Filtered Output Word Rate | 2.5 MHz |
| Total Power Dissipation (Normal Mode) | 958 mW max |
| Operating Temperature Range | -40 °C to +85 °C |
| Package | 64‑Lead Thin Quad Flat Package, Exposed Pad (TQFP_EP) |
| Resolution | 24 bits |
The AD7760 provides a dynamic range of 120 dB at a 78 kHz output data rate.
In normal mode the AD7760 dissipates up to 958 mW of power.
The AD7760 is offered in an exposed‑paddle 64‑lead TQFP package.
The device is specified for commercial temperature range from –40 °C to +85 °C.
