The OP183 is a single-supply, 5 MHz bandwidth amplifier with slew rates of 10 V/μs. It can operate from voltages as low as 3 V and up to 36 V. This combination of slew rate and bandwidth yields excellent single-supply ac performance, making this amplifier ideally suited for telecom and multimedia audio applications. The OP183 also provides good dc performance with guaranteed 1 mV offset. Noise is a respectable 10 nV/√Hz. Supply current is only 1.2 mA per amplifier. This amplifier is well-suited for a variety of applications, including multimedia, telecom, ADC buffers, wide band filters, and microphone preamplifiers.
The OP183 is a 9 MHz single‑supply operational amplifier designed for multimedia, telecom, ADC buffers, and headphone driver applications. It operates from 3 V to 36 V, offers a typical slew rate of 10 V/s, low offset voltage (1 mV), low noise (10 nV/√Hz) and a unity‑gain stable design with input and output ranges that include ground.
The datasheet lists detailed electrical characteristics at supply voltages of 3 V, 5 V and 15 V, absolute maximum ratings, typical performance curves, package dimensions, and ordering options for the SO‑8 surface‑mount package. It also includes application notes such as low‑voltage frequency synthesizer use in wireless transceivers.
| Supply Voltage Range | 3 V to 18 V |
|---|---|
| Slew Rate | 10 V/s |
| Gain Bandwidth Product | 5 MHz |
| Voltage Noise Density | 10 nV/√Hz at 1 kHz |
The OP183 operates from 3 V up to 18 V supply voltage.
At a 5 V supply the OP183 has a typical slew rate of 10 V/s.
The gain‑bandwidth product is specified as 5 MHz.
