This document introduces NXP Semiconductors' portfolio of LED solutions for gaming, mobile, signage, LCD TV backlighting, LED indication, and more. These solutions are designed for high performance, low cost, high power efficiency, and flexible design. They also include Fast-mode Plus, a wide supply range (2.3 to 5.5 V), and flexible PWM functions. They also have ultra-low standby modes (<1 µA), low CPU overhead, and extended battery life in mobile applications. These solutions also include application boards and daughter cards, and have a mature manufacturing infrastructure that supports high volumes. They provide everything you need to make lighting affordable, from mobile handsets and gaming systems to outdoor billboards, signage, and more.
This brochure presents NXP's portfolio of I²C‑bus LED driver ICs, highlighting power‑efficient designs, flexible PWM functions, and low‑standby‑current operation for a wide range of lighting applications. It includes application‑specific benefits for gaming, mobile devices, TV backlighting, and signage, as well as links to reference boards and high‑volume manufacturing capabilities.
The document details several product families such as the PCA962x, PCA963x, PCA9685, PCA9901, PCA9922/9926, and PCA953x/955x series, providing key specifications like supply voltage ranges, PWM resolution, interface speed, and output current capabilities. Packaging options and sales‑office information are also provided.
| Supply voltage range | 2.3 to 5.5 V |
|---|---|
| PWM step resolution (PCA962x/963x) | 256 steps |
| PWM step resolution (PCA9685) | 4096 steps |
| I²C bus speed | 1 MHz and 30 mA |
| Typical output current | 5 V, 25 mA for all outputs |
| Standby power consumption | < 1 pA (ultra‑low) |
| I²C mode | Fast‑mode Plus |
They operate from 2.3 V up to 5.5 V.
The PCA9685 offers 4096 PWM steps per channel.
The PCA9632 family provides ultra‑low standby mode (< 1 pA).
The I²C bus operates at 1 MHz with a 30 mA drive capability.
