This document provides information about the hardware installation, driver installation instructions, and BIOS settings of the Colorful C.N78G Ver1.4 motherboard. The motherboard features include the use of NVIDIA MCP78V chipset design, support for AM2 and AM2+ socket processors, support for HT3.0 and PCI-E 2.0, support for AMD Socket AM2 processors, support for various DDR2 memory specifications, built-in GeForce 8 series display core, support for DX10.0 and Shader Model 4.0, and support for Hybrid SLI technology.
This manual provides step‑by‑step instructions for installing the C.N78G Ver1.4 motherboard, connecting hardware components, and installing drivers. It also details BIOS configuration, power‑management features and troubleshooting tips.
The document lists all connectors, expansion slots and supported CPUs and memory types, and includes a parts diagram, jumper settings and contact information for technical support. This manual is written in Chinese.
| Form factor | mATX |
|---|---|
| Chipset | NVIDIA MCP78V |
| Supported memory | DDR2 400/533/667/800/1066 |
| PCI Express slots | 1 × PCIe x16, 1 × PCIe x1 |
| Audio | 8‑channel audio codec |
The motherboard uses the NVIDIA MCP78V chipset.
It supports DDR2 memory up to 1066 MHz in dual‑channel mode.
