ASUS ADSL Modem/Router User Manual

ADSL CXXX 2 ADSL is a ADSL modem produced by Huawei. The device supports PPPoE, PPPoA, MPoA, IPoA, etc. And it provides DHCP Server, DHCP Relay, NAT, IP Filter, IGMP Proxy, RIP, DNS Relay, ATM OAM, ATM QoS etc.

Brand: ASUS
Category: Router
Document type: User Manual
Language: Chinese
Pages: 36
File format: PDF
File size: 2.1 MB
Published: 20 March, 2012
Updated: 30 September, 2023
MD5 checksum: 9137AFBC7F585310F11A6B958524FB20
PDF: ASUS ADSL Modem/Router User Manual PDF

About this manual

The manual introduces the ASUS ADSL modem/router, describing its features and the supported networking protocols such as PPP over ATM, DHCP, NAT, and IGMP Proxy. It guides users through hardware installation, including front and rear panel connections and LED indicator meanings.

Detailed steps cover TCP/IP configuration for Windows ME and Windows 2000, checking network settings, and performing firmware updates via TFTP. An appendix lists ADSL‑related terminology and standards for reference. This manual is written in Chinese.

What's inside

Introduction
Installation
TCP/IP Settings
Front Panel and LED Indicators
Rear Panel Connections
Management Control Panel
Basic Configuration
Software Update
Appendix

Specifications

Default LAN IP address	192.168.1.2
Default subnet mask	255.255.255.0
Supported protocol	RFC 2364 (PPP over ATM)
Power LED function	Indicates power is on
Reset button	Reboots the modem/router

Frequently asked questions

How do I set the LAN IP address on the ASUS ADSL modem/router?

Open the TCP/IP settings, set the IP address to 192.168.1.2 and the subnet mask to 255.255.255.0.

How do I reset the ASUS ADSL modem/router?

Press the Reset button on the rear panel to restart the modem/router.
