The ASUS S370-DL CPU card allows Slot 1 motherboards to accept socket 370 processors with Front Side Bus running at up to 133MHz. The S370- DL CPU card supports single Coppermine/Celeron and dual Coppermine/ Celeron (PPGA only) processors to give Slot 1 motherboard owners an inexpensive way to upgrade their Pentium II/III computers using lower costing socket 370 processors. Since socket 370 processors are designed on the Pentium II/III design, the only difference is the package form factor. Additionally, the S370-DL CPU card can acquire temperature data from the processor’s thermal diode and send it to the motherboard that supports CPU thermal monitoring.
The ASUS S370-DL CPU card allows Slot 1 motherboards to accept socket 370 processors with a Front Side Bus up to 133 MHz. It supports single and dual Coppermine/Celeron processors and can report temperature data to compatible motherboards.
The guide explains how to set the CPU voltage jumpers, install the processor and heatsink, mount the card in the Slot 1 connector, and connect the fan power. Safety warnings advise using the default voltage setting unless the processor specifies otherwise.
| Supported processor socket | Socket 370 |
|---|---|
| Front Side Bus speed | up to 133 MHz |
Lift the brown lever to 90°, place the processor, then lower the lever to lock it in place before attaching the CPU fan heatsink.
Exceeding the required voltage can permanently damage the processor, so keep the jumpers set to the default unless the processor specifies otherwise.
