TL-R473/TL-R483 is a high-speed broadband router specially developed by Shenzhen TP-Link Technology Co., Ltd. for small businesses, offices and small Internet cafes. It supports 4*10/100M adaptive ports, supports 2.4G wireless transmission, supports VPN, QoS, DHCP, DDNS and other functions.
The guide provides an overview of the TL-R473/TL-R483 routers, describing their hardware features, front and rear panel layouts, indicator LEDs, and supported network standards. It is intended for network engineers and administrators who need to install and configure the devices in small‑business or office environments.
It covers step‑by‑step hardware installation, wiring connections, reset procedures, initial configuration via the web interface, troubleshooting tips, and includes a technical specifications table for reference. This manual is written in Chinese.
| TL-R473 LAN ports | 4 x 10/100M RJ45 (Auto MDI/MDIX) |
|---|---|
| TL-R473 WAN ports | 1 x 10/100M RJ45 (Auto MDI/MDIX) |
| TL-R483 LAN ports | 1 x 10/100M RJ45 (Auto MDI/MDIX) |
| TL-R483 WAN ports | 1 x 10/100M RJ45 (Auto MDI/MDIX) |
| Power input | 100‑240 V, 50/60 Hz, 0.3 A |
| Dimensions | 209 mm × 126 mm × 26 mm |
| Storage temperature | -40 °C ~ 70 °C |
| Operating humidity | 10 % ~ 90 % RH (non‑condensing) |
| Storage humidity | 20 % ~ 90 % RH (non‑condensing) |
The default management address is 192.168.1.1 and the default username and password are both admin.
While the router is powered on, press and hold the RESET button until the system LED flashes five times, then release the button; the router will restore factory settings and reboot.
