This document introduces the TL-POE10R PoE splitter product from TP-LINK. The product follows the IEEE 802.3af standard and can provide 5V, 9V, or 12V DC power to devices that do not support PoE. The product features plug and play, elegant appearance, and space-saving design.
The TL-POE10R PoE separator from TP‑Link complies with IEEE 802.3af and delivers selectable 5 V, 9 V or 12 V DC power to devices that lack PoE support. It works with any PoE‑enabled switch or injector and uses a standard 5‑class unshielded twisted‑pair cable.
Installation is simple: connect the POWER+DATA IN port to a PoE source, set the desired output voltage with the switch, then link the LAN OUT port to the target device and use the DC OUT port for its power connection. The unit includes status LEDs and operates in a temperature range of 0 °C to 40 °C. This manual is written in Chinese.
| Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3af |
|---|---|
| Output Voltage | 5 V, 9 V, 12 V DC |
| Output Power | 10 W (5 V), 9 W (9 V), 12 W (12 V) |
| Ports | 2 × 10/100 Mbps RJ45, 1 × DC power |
| Operating Temperature | 0 °C ~ 40 °C |
| Storage Temperature | -40 °C ~ 70 °C |
It can output 5 V, 9 V or 12 V DC.
The device supplies up to 10 W at 5 V, 9 W at 9 V, or 12 W at 12 V.
