TL-SF1008P 8-Port PoE Switch is a 10M/100M non-managed PoE switch (PSE) that supports IEEE 802.3af standard. TL-SF1008P can provide power for PoE powered devices such as IP telephones, wireless APs, network cameras, etc.
The TL‑SF1008P is an 8‑port 10/100 Mbps unmanaged PoE switch that supplies power to IEEE 802.3af‑compliant devices such as IP phones, wireless APs, and cameras. Four of the ports support PoE with a total power budget of 53 W.
The manual provides a product overview, installation steps, panel descriptions, and technical specifications, including power consumption, operating temperature, and LED indicators for status monitoring. This manual is written in Chinese.
| Number of ports | 8 |
|---|---|
| Maximum PoE power per port | 15.4 W |
| Total PoE power budget | 53 W |
| Power consumption (no PoE load) | 5.8 W |
| Power consumption (full PoE load) | 58 W |
| Operating temperature | 0 °C ~ 40 °C |
| Storage temperature | -40 °C ~ 70 °C |
| IEEE standards supported | 802.3, 802.3u, 802.3x, 802.3af |
Each PoE port can supply up to 15.4 W of power.
The switch can deliver a total of 53 W across all PoE ports.
