This manual covers safety precautions, pre‑use checks, and installation requirements for the Sampo AM‑PY63D indoor and outdoor units. It explains how to connect piping, electrical wiring, and set up the remote controller, as well as recommended mounting height and grounding details.
The guide also describes normal operation modes such as cooling, timer, sleep, and additional functions like wind direction adjustment and power‑saving. Maintenance, troubleshooting, and a full specification table are included for service technicians and end users. This manual is written in Japanese.
| Indoor unit dimensions (W×H×D) | 1150 x 300 x 260 mm |
|---|---|
| Outdoor unit dimensions (W×H×D) | 950 x 800 x 300 mm |
The manual recommends mounting the indoor unit at a height of about 2.5 m.
The indoor side has an IPX0 rating, while the outdoor side is rated IPX4.
Press the timer key to schedule a power‑on or power‑off time; the key can also cancel the schedule.
