This manual provides safety guidelines, pre‑use precautions, and detailed descriptions of each component of the AM‑A75 series indoor and outdoor units. It explains the functions of the control panel, remote, and airflow direction settings, and includes troubleshooting tips.
Installation sections cover indoor unit mounting, outdoor unit placement, refrigerant piping, and electrical grounding. Operation instructions describe temperature setting, fan speed, swing mode, timer functions, and energy‑saving tips, while the maintenance chapter outlines filter cleaning, periodic checks, and battery replacement procedures. This manual is written in Chinese.
| Indoor unit dimensions (mm) | 1412 x 385 x 220 |
|---|---|
| Outdoor unit dimensions (mm) | 950 x 800 x 300 |
The indoor and outdoor units should be installed at least 15 cm apart.
