This manual covers safety guidelines, installation steps, wiring, grounding, and required clearances for the AW‑QA25 indoor unit. It also explains how to connect the drainage pipe, set up the remote controller, and adjust temperature and fan settings.
Additional sections describe routine maintenance, cleaning procedures, specifications, and a troubleshooting guide for common faults such as no cooling, abnormal noises, or error codes. This manual is written in Japanese.
| Model | AW-QA25 |
|---|---|
| Dimensions (mm) | 600 x 380 x 700 |
| Voltage | 250 V |
Install the indoor unit at a height of 100‑150 cm, ensure proper grounding, and keep the required clearances for air intake and exhaust.
When cleaning the interior, use a dry cloth or mild warm water; do not use water above 40 °C or solvents that could damage the surface.
