This manual covers safety precautions, required grounding, and installation guidelines for both indoor and outdoor units, including pipe routing and mounting heights. It also explains the functions of each component, remote‑control operation, and emergency handling procedures.
Technical specifications such as dimensions, power ratings, voltage, and performance figures are listed, along with recommended operating settings and maintenance tips like filter cleaning and periodic checks. This manual is written in Chinese.
| Indoor unit dimensions | 790 × 270 × 180 mm |
|---|---|
| Outdoor unit dimensions | 880 × 530 × 220 mm |
The indoor unit should be installed at least 20 cm above the floor and preferably 25 cm or higher.
The remote control works up to about 7 meters from the receiver.
Ensure that the unit is properly grounded and follow all safety precautions listed in the manual.
