This manual explains how to prepare the Sampo AL‑A28M air purifier for first use, including placing the unit on a flat surface, installing the activated‑carbon filter, and connecting the power cord to an AC110 V 60 Hz outlet. It also covers operating the control panel, adjusting fan speed, and the recommended placement distance from TVs, microwaves and other electronic devices.
Safety precautions are highlighted, such as avoiding combustible gases, not using the unit in bathrooms or near strong sunlight, and never cleaning the filter with water or solvents. The troubleshooting section lists common fault symptoms and steps to resolve them, while the specifications table provides the rated voltage, power consumption, dimensions, weight and suitable room size. This manual is written in Chinese.
| Rated voltage | AC110 V 60 Hz |
|---|---|
| Power consumption | 28 W |
| Power cord length | 1.8 m |
| Dimensions (W×H×D) | 320 mm × 250 mm × 112 mm |
| Net weight | 1.8 kg |
| Gross weight | 2.1 kg |
| Applicable room area | up to 4 pings |
Remove the white activated‑carbon filter, check its color against the indicator sticker, and replace it when the colors match; do not wash the filter with water.
Turn off the power, unplug the unit, and contact the company for after‑sales service.
No, do not use stain‑removing powder, volatile oils, or alcohol when cleaning the unit, as they can damage it.
