The manual begins with safety regulations, emphasizing the need to disconnect power before service, ensure proper grounding, and avoid installation in damp locations. It also details the required clearances for indoor intake (minimum 50 cm) and outdoor exhaust (minimum 100 cm) to guarantee safe operation.
Subsequent sections cover the installation procedure, component identification, operating controls, regular maintenance, and a troubleshooting guide. A specifications table lists dimensions, voltage, power consumption, and performance figures for each model in the AW‑P20R family. This manual is written in Chinese.
| Model | AW-P20R |
|---|---|
| Dimensions (mm) | 520 × 345 × 543 |
Power must be disconnected, the grounding wire must be connected before any other wiring, and the unit should not be installed in humid places such as bathrooms or laundry rooms.
The indoor intake must have at least 50 cm of free space, and the outdoor exhaust must have at least 100 cm of clearance.
