Fagor CNC 8035 Manual

This document is the CNC 8035 milling machine operator's manual, which details the machine's operation methods, including overview, operating mode, execution/simulation, editing, etc.

Brand: Fagor
Category: Industrial Robot
Document type: User Manual
Language: English
Pages: 205
File format: PDF
File size: 3.5 MB
Published: 16 March, 2012
Updated: 30 September, 2023
Model: CNC 8035
MD5 checksum: C8B2F76AA28AB80F9B8731B86BCC20F8
PDF: Fagor CNC 8035 Manual PDF

About this manual

This document describes the hardware components, configuration options, and basic operation of the Fagor CNC 8035. It includes sections on memory cards, compact flash, PLC interface, and RS‑232 communication.

Additional chapters cover routine maintenance procedures, troubleshooting tips, and specifications such as RAM size and power requirements, helping users keep the machine running reliably.

What's inside

System Overview
Memory Card and Compact Flash
Hard Disk
PLC Interface
RS‑232 Communication
Maintenance Procedures
Troubleshooting
Technical Specifications

Specifications

RAM	256 KB
Communication Port	RS‑232
Power Supply	5 V
Compact Flash Support	Yes

Frequently asked questions

What type of memory is used in the CNC 8035?

The system uses 256 KB of RAM and supports a Compact Flash card for additional storage.

Which communication interface is provided?

The CNC 8035 includes an RS‑232 serial port for external communication.

What is the required power input for the controller?

The controller operates from a 5 V power source.
