Featured Fagor manuals
FAGOR MAN REGUL (IN) Servo-Drive System General Manual
This manual covers the FAGOR Servo‑Drive System, identified as model MAN REGUL (IN) Version 0002. It describes the system architecture, the range of power‑supply modules (XPS‑25, XPS‑65, PS‑25A, PS‑25B, PS‑65A, APS 24) and compatible motors (Brushless AC FMX, AXM and asynchronous SPM), as well as the software version (04.01) used for configuration.
The document includes detailed installation and mounting instructions, wiring diagrams, connector descriptions, parameter settings, protection features (I2t monitoring, ballast‑resistor protection), and troubleshooting guides. Appendices list error codes, product references, and example PLC programs for gear‑ratio changes and spindle control.
Covers: General Characteristics · Electrical Characteristics · Dimensions · Brake Characteristics · Connectors · Installation and Mounting Conditions
FAGOR Oven User Manual
This manual explains the safe use of the FAGOR oven, including important safety notices, child‑safety measures, and precautions to avoid damage or injury. It also covers the required steps before first use and the importance of keeping the manual for future reference.
The guide details installation and assembly, connection to mains electricity, operation instructions, cleaning and maintenance procedures, troubleshooting advice, and environmental and energy‑saving recommendations.
Covers: Safety Notices · Installation and Assembly · Use and Operation · Care and Cleaning · Troubleshooting · Environmental Note
FAGOR 20i-T/30i-T20i-TB/30i-TB installation /Manual
The 20i-T and 30i-T are digital readout (DRO) devices that display axis positions on an 8‑digit LED panel. They support up to three axes and include functions such as tool preset, absolute/incremental modes, and quick‑setting shortcuts.
This manual covers the front‑panel layout, power‑on procedure, installation steps, wiring connections, parameter configuration, error‑code reference, and recommended maintenance practices. This manual is written in Chinese.
Covers: Overview · Front Panel · Power On/Off · Display Modes (Absolute, Incremental, Radius/Diameter) · Tool Preset Management · Installation
Fagor 20i-M / 30i-M Digital Readout Installation and Operation Manual
The document describes how to install and operate the Fagor 20i-M and 30i-M digital readouts used on machine tools. It covers front‑panel functions, power‑on procedures, display modes, tool‑radius compensation, and special functions such as linear and circular hole machining.
Additional sections explain mounting options, connection diagrams, quick‑setup mode, safety warnings, error‑code reference, and maintenance recommendations to keep the readout reliable in industrial environments. This manual is written in Chinese.
Covers: Overview · Operation · Installation · Display Modes · Tool Compensation · Special Functions
Latest Fagor manuals
FAGOR MAN REGUL (IN) Servo-Drive System General Manual
User Manual 364 pages · 5.9 MB · ENThe FAGOR MAN REGUL (IN) Servo-Drive System General Manual provides installation, setup, and technical information for the drive and motor modules.
FAGOR Oven User Manual
User Manual 40 pages · 1.1 MB · ENThe FAGOR oven user manual provides safety notices, installation, operation, cleaning, maintenance, troubleshooting, and energy‑saving tips.
FAGOR SURFACE MOUNT TRIAC
FT08.D surface mount triac is a surface mount triac produced by Fagor company. It has high performance PNPN technology and is suitable for AC control applications
FAGOR RGP15A handbook
This document provides the mounting instructions, maximum ratings, and electrical characteristics of RGP 15A 50 RGP15A..RGP15MT 1.5 Amp. Glass Passivated Fast Recovery Rectifier.
FAGOR FB1000...FB1010 Data Sheet
FB1000-FB1010 10 Amp. Glass Passivated Bridge Rectifier, rated voltage 50~1000V, rated current 10A. Features include: Glass Passivated Junction, UL recognized, terminals are FASTON and WIRE LEADS, with lead and polarity identifications, high surge current capability.
FAGOR FS02...N SURFACE MOUNT SCR
The FS02.N SURFACE MOUNT SCR is a silicon controlled rectifier produced by Fagor. It has high-performance PNPN technology and is suitable for general-purpose applications that require high gate sensitivity using surface mount technology.
FAGOR FUF4001........ FUF4007 Manual
FUF4001.. FUF4007 1 Amp. Glass Passivated Ultrafast Recovery Rectifier • Glass Passivated Junction • High current capability • The plastic material carries U/L recognition 94 V-0 • Terminals: Axial Leads • Polarity: Color band denotes cathode
FAGOR BZY97C10 GP........ BZY97C200 GP Data Sheet
BZY97C10 GP.. BZY97C200 GP 1.5 W Zener Diodes are 1.5W Zener diodes with a working voltage range of 10-200V. The package type is DO-41 (Plastic) and the rated current is 10 mA. The maximum power is 40 W and the operating temperature range is -55 to +175 °C. The storage temperature range is -55 to +175 °C.
FAGOR 1N5343B........1N5388B DATA SHEET
1N5343B..1N5388B 5W Glass Passivated Zener Diode is used for high power applications, with high temperature stability and low leakage current.
FAGOR NV-300E/NV-301E Installation Guide
FAGOR AUTOMATION CNC 8035 Manual
This document is the CNC 8035 milling machine operator's manual, which details the machine's operation methods, including overview, operating mode, execution/simulation, editing, etc.
FAGOR AUTOMATION CNC 8035 Installation Guide
CNC 8035 Installation Manual
FAGOR CNC 8055 CNC 8055i Manual
FAGOR 20i-T/30i-T20i-TB/30i-TB installation /Manual
User Manual 32 pages · 608 KB · ZHThe Fagor 20i-T / 30i-T digital readout manual provides installation, operation, parameter settings, error codes and maintenance instructions.
Fagor 20i-M / 30i-M Digital Readout Installation and Operation Manual
Installation Guide 40 pages · 727 KB · ZHThis manual provides installation instructions, operation guidance, and troubleshooting for the Fagor 20i-M and 30i-M digital readouts.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Installation Guide
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in Fagor manuals
What warranty period does FAGOR provide for its products?
All FAGOR products carry a 12‑month warranty for the end user, with the start date based on the installation date recorded on the warranty form.
From: FAGOR MAN REGUL (IN) Servo-Drive System General Manual
How can the I2t level of the drive be monitored?
The I2t level can be read through the variable KV32‑F01109‑I2tDrive (for the drive) or KV36‑F01111‑I2tMotor (for the motor).
From: FAGOR MAN REGUL (IN) Servo-Drive System General Manual
How do I replace the interior light bulb?
Refer to section 4.2 titled “How to replace the bulb in the interior light”.
From: FAGOR Oven User Manual
What safety precautions should I follow when using the oven?
Never operate the oven with the door open, keep children away, do not pour water on a hot oven, use oven gloves, and always turn controls to the “0” position after use.
From: FAGOR Oven User Manual
How do you turn the digital readout on?
Press the on/off key; the display powers up automatically and shows “FAGOR DRO” or an error code.
How many tool presets can be stored?
The device can store up to 20 tool preset parameters, numbered from tool 0 to tool 19.
