This manual details the technical specifications of the Konica Minolta magicolor 5430DL and 5440DL high‑speed black‑white laser printers, including print speeds, resolution options, and supported media sizes. It also lists the physical dimensions, power requirements, and memory configuration.
Connectivity options such as Ethernet 10/100Base‑TX with full TCP/IP protocol support and USB 2.0 Hi‑Speed are described, along with compatible operating systems for both Windows and Macintosh platforms. Contact information for service and sales is provided at the end of the document.
| Print speed (A4) | 25 ppm |
|---|---|
| Print speed (Letter) | 27 ppm |
| Resolution options | 2400 × 600 dpi, 1200 × 600 dpi, 600 × 600 dpi |
| Ethernet interface | 10/100Base‑TX with TCP/IP, IPP, DHCP, BOOTP, HTTP, SNMP, SLP, LPR |
| USB interface | USB 2.0 Hi‑Speed |
| Memory | 64 MB standard, up to 576 MB optional |
| Power input | 220‑240 V AC, 50/60 Hz |
| Dimensions (W × D × H) | 425 mm × 520 mm × 440 mm |
| Supported operating systems | Windows Server 2003/XP/2000/NT4.0/ME/98SE, Macintosh OSX v10.2+ |
It includes an Ethernet 10/100Base‑TX port supporting TCP/IP, IPP, DHCP, BOOTP, HTTP, SNMP, SLP, LPR, and a USB 2.0 Hi‑Speed port.
The unit measures 425 mm wide, 520 mm deep, and 440 mm high.
Supported OSes are Windows Server 2003/XP/2000/NT4.0/ME/98SE and Macintosh OSX version 10.2 or later.
