ASRock G31M-VS2 is a mini ATX motherboard designed by ASRock with G31 chipset.
This manual covers the ASRock G31M-VS2 motherboard, detailing the layout of its components and connectors. It includes reference numbers and labels used throughout the board.
Key connector information such as the four SATAII ports (SATAII_1‑SATAII_4) and the CD drive connector (CD1) are listed, helping users locate and connect peripherals correctly.
| Model | G31M-VS2 |
|---|---|
| SATA ports | 4 |
It has four SATAII ports, labeled SATAII_1 through SATAII_4.
