This document introduces the features and characteristics of ASRock H61M-PS motherboard, including its strict manufacturing, reliability, and excellent performance. It also provides detailed information such as installation guide and motherboard specifications.
The ASRock H61M-PS Quick Installation Guide provides an overview of the motherboard’s layout, connectors, and key features. It includes a brief introduction, package contents, and a concise specifications table.
The guide also details installation procedures such as CPU and memory installation, BIOS setup, and OS installation on large hard drives, plus notes on the integrated utilities and safety warnings.
| Form Factor | Micro ATX (9.6‑in x 7.8‑in) |
|---|---|
| CPU Socket | LGA1155 |
| Chipset | Intel® H61 |
| SATA Connectors | 4 × SATA2 3.0 Gb/s (NCQ, AHCI, Hot‑Plug) |
| LAN | Gigabit LAN (Atheros AR8151) |
It uses an LGA1155 socket for 2nd‑generation Intel Core i7/i5/i3 processors.
An Atheros AR8151 Gigabit LAN controller is built in.
Yes, its UEFI BIOS supports OS installation on HDDs larger than 2 TB.
