ASRock UEFI Setup Utility User Manual

Q: How do I enter the UEFI Setup Utility?

Press or during the Power‑On Self‑Test (POST) to launch the UEFI SETUP UTILITY.

This document is an introduction to the UEFI setup program, including how to use the UEFI SETUP UTILITY to configure the system and the functionality of each menu. It also introduces the system browser and overclocking settings.

Brand: ASRock
Category: Upgrade guide
Document type: User Manual
Language: Chinese
Pages: 22
File format: PDF
File size: 418 KB
Published: 14 March, 2012
Updated: 28 September, 2023
MD5 checksum: 05591E14AA54E45DCEBD6D7EA003D712
PDF: ASRock UEFI Setup Utility User Manual PDF

About this manual

This manual describes how to launch the UEFI SETUP UTILITY from the POST screen (press F2 or Del) and navigate its menus using keyboard shortcuts or the mouse. It covers the main screen, system overview, and detailed configuration pages for CPU, memory, voltage, and advanced features.

The guide also provides instructions for using Instant Flash to update the UEFI firmware, setting default values, saving or discarding changes, and configuring security, boot order, and fan controls. Safety warnings are included for overclocking and voltage adjustments. This manual is written in Chinese.

What's inside

Introduction
Navigation Keys
Main Screen
Overclocking Settings
Advanced Settings
Voltage Control
Instant Flash
CPU Configuration
Hardware Health Monitoring
Boot Screen

Specifications

CPU Core Voltage default	Auto
VCCSA Voltage default	Auto
DRAM Voltage default	Auto

Frequently asked questions

How do I enter the UEFI Setup Utility?

Press or ~~during the Power‑On Self‑Test (POST) to launch the UEFI SETUP UTILITY.~~

What is the purpose of the Instant Flash feature?

Instant Flash allows you to update the UEFI firmware from a USB flash drive or hard disk without first booting an operating system.
