LT7310 controller is a high-performance motion control system. This manual introduces the specifications and usage methods of LT7310. Please fully understand the usage of LT7310 before using it.
This manual introduces the LT7310 controller, a high‑performance control unit developed by Leetro Automation. It outlines safety warnings, including protection against moisture, explosive atmospheres, and electro‑static discharge, and describes the warranty terms.
The document details installation procedures, hardware layout, connection methods, and hardware testing functions such as limit‑switch checks, magnetic sensor verification, and stepper‑motor signal output. It also lists the controller’s key specifications, interfaces, and dimensions. This manual is written in Chinese.
| Memory | 64M |
|---|---|
| Display | 3.5‑inch color LCD |
| AC Input | 220 V / 50 Hz |
| Magnetic sensor output | 1 signal |
| Limit‑switch inputs | 2 signals |
| Printer input | 1 signal |
| Stop signal input | 1 signal |
| USB ports | 2 |
| Dimensions | 245 mm × 220 mm × 100 mm |
Connect a 220 V AC 50 Hz power source to the controller’s AC input terminals, ensuring the correct polarity and that the power is switched off before making connections.
The controller measures 245 mm in width, 220 mm in depth, and 100 mm in height.
