GA-G41MT-S2 is a motherboard released by Gigabyte Technology Co., Ltd. on June 24, 2011. The motherboard features GA-G41MT-S2 motherboard configuration diagram and GA-G41MT-S2 motherboard functional block diagram, providing detailed instructions for hardware installation and BIOS configuration. The motherboard supports installation of central processing unit and cooling fan, installation of memory modules and interface cards, and provides socket and jumper introductions. In addition, the motherboard has BIOS configuration functions, including frequency/voltage control, standard CMOS settings, advanced BIOS feature settings, integrated peripheral settings, power management setup, etc. The document also provides a guide for driver installation.
This manual provides step‑by‑step hardware installation instructions, safety precautions, and detailed BIOS configuration guidance for the Gigabyte GA‑G41MT‑S2 motherboard. It also lists the supplied accessories and explains how to correctly connect power, CPU, memory, and peripheral devices.
The document includes a full specification sheet, warranty terms for Taiwanese customers, and contact information for technical support. All sections are presented in Chinese with reference to Gigabyte’s official website for additional resources. This manual is written in Chinese.
| CPU Socket | LGA775 |
|---|---|
| Memory Slots | 2 DDR3 DIMM slots, up to 8 GB total |
| Audio Codec | VIA VT1708SI / Realtek ALC887, supports HD audio |
| LAN | Atheros AR8151 Gigabit Ethernet |
| PCI Express Slots | 1 × PCI‑Express x16, 2 × PCI‑Express x1 |
| SATA Ports | 4 × SATA 3 Gb/s connectors |
| USB Ports | Up to 8 × USB 2.0/1.1 ports |
| Power Connectors | 1 × 24‑pin ATX, 1 × 4‑pin ATX 12 V |
The model number is GA‑G41MT‑S2.
It supports up to eight USB 2.0/1.1 ports.
The warranty period is three years.
It uses an LGA775 socket.
