GA-A55-S3P is a motherboard produced by Gigabyte Technology Co., Ltd. It has various functions and features, including support for AMD Dual Graphics system, support for installation of multiple interface cards, and introduction of rear device sockets.
This manual covers safety precautions, hardware installation steps, and BIOS configuration for the GA‑A55‑S3P motherboard. It explains how to prepare the work area, handle the board with anti‑static measures, connect power and peripheral cables, and configure BIOS settings such as memory timings and power management.
The document also lists the technical specifications of the board, including supported CPUs, memory types, expansion slots, and I/O connectors, and provides warranty terms and contact information for technical support. This manual is written in Chinese.
| CPU Socket | FM1 |
|---|---|
| Supported Chipsets | AMD A75/A55 |
| Maximum Memory Capacity | 16 GB DDR3 DIMM |
| Supported Memory Speeds | DDR3 1866/1600/1333/1066 MHz |
| SATA Ports | 6 × SATA 3 Gb/s |
| USB Ports | 12 × USB 2.0 |
| PCI Express Slots | 1 × PCIe x16, 4 × PCIe x1 |
| Audio Codec | Realtek ALC887 |
| LAN Controller | Realtek RTL8111E |
| HDMI Output Resolution | Up to 1920 × 1200 |
The board provides six SATA 3 Gb/s ports for connecting storage devices.
The warranty period is three years from the date of purchase.
