This manual provides step‑by‑step instructions for installing the GA‑H61MA‑D3V motherboard, including hardware preparation, CPU and memory installation, and connector wiring. It also details BIOS configuration options and driver installation procedures.
Additional sections cover the motherboard’s specifications, connector layouts, power‑up safety guidelines, and warranty information, helping users set up and maintain the system safely and efficiently. This manual is written in Chinese.
| CPU Socket | LGA1155 |
|---|---|
| Memory Slots | 2 DDR3 DIMM slots, up to 16 GB |
| Supported Memory Speed | DDR3 1333/1066/800 MHz |
| Chipset | Intel® H61 |
| PCI Express Slots | 1 × PCIe x16, 3 × PCIe x1 |
| USB Ports | 8 × USB 2.0/1.1, 2 × USB 3.0/2.0 (rear) |
| LAN Controller | Realtek/Atheros GbE (10/100/1000 Mbit) |
| Form Factor | Micro ATX (24.4 cm × 17.4 cm) |
It uses an LGA1155 socket for Intel® Core i7, i5, i3, Pentium, and Celeron processors.
The board has two 1.5 V DDR3 DIMM slots supporting up to 16 GB of memory.
Yes, it includes two USB 3.0/2.0 ports on the rear I/O panel.
A Realtek/Atheros Gigabit Ethernet controller (10/100/1000 Mbit) is built in.
