Gigabyte GA-G41MT-S2PT Motherboard User Manual

This manual is a user guide for the GA-G41MT-S2PT motherboard, providing information on hardware installation and BIOS configuration.

Brand: Gigabyte
Category: Motherboard
Document type: User Manual
Language: English
Pages: 40
File format: PDF
File size: 10.2 MB
Published: 13 March, 2012
Updated: 28 September, 2023
Model: GA-G41MT-S2PT
MD5 checksum: 3F6684C2ACA96ECC707526639F9665A3
PDF: Gigabyte GA-G41MT-S2PT Motherboard User Manual PDF

About this manual

This manual covers the installation of the GA‑G41MT‑S2PT motherboard, including CPU, memory, and peripheral connections. It provides step‑by‑step instructions for safely handling the board, installing the processor, attaching fans, and connecting power and data cables.

The document also details BIOS setup options, supported CPUs and memory types, connector layouts, and compliance and warranty terms. Technical specifications such as chipset, LAN, audio, expansion slots, SATA and USB ports are listed for reference.

What's inside

Hardware Installation
CPU Installation
BIOS Setup
Connector Layout
Specifications
Warranty and Support
Safety and Compliance

Specifications

CPU Socket	LGA775
Memory Speed	DDR3 1333 / 1066 / 800 MHz
Chipset	Intel G41
Audio Codec	Realtek/VIA HD Audio
SATA Ports	4 SATA 3 Gb/s ports
USB Ports	Up to 8 USB 2.0/1.1 ports
Power Connectors	24‑pin ATX main, 4‑pin ATX 12 V

Frequently asked questions

What type of CPU socket does the GA‑G41MT‑S2PT motherboard use?

The motherboard uses an LGA775 socket.

How many SATA ports are available on this motherboard?

There are four SATA 3 Gb/s ports.
