This product is a high-resolution dispersion test solution that can provide accurate testing of standard and low PMD values for any optical fiber link, while also qualifying CD and spectral attenuation (SA).
The High‑Resolution Dispersion Test Solution integrates a femtosecond PMD analyzer, broadband light source, and software for fast, repeatable fiber‑characterization. It supports measurement of polarization mode dispersion (0 fs‑18 ps), chromatic dispersion, and spectral attenuation, and is battery‑operated for field use.
Two configurable kits are offered: Kit 1 pairs a T‑BERD/MTS‑8000 platform with a PMD analyzer and a T‑BERD/MTS‑6000 platform with a broadband source; Kit 2 provides both functions on a single T‑BERD/MTS‑8000 platform. A Windows‑based PC application generates customizable reports with OTDR, CD, PMD, and attenuation data.
| PMD measurement range | 0 fs to 18 ps |
|---|---|
| Dynamic range (PMD) | 48 dB |
| Measurement time (PMD) | 30 s |
| Wavelength uncertainty (Kit 2) | ±0.1 nm |
| Attenuation uncertainty at 1550 nm | 0.003 dB/km |
| Spectral range (Broadband Source) | 1460‑1640 nm |
| Typical output power | 11 dBm |
The solution measures polarization mode dispersion from 0 fs up to 18 ps.
No, the broadband source requires no warm‑up time.
Kit 1 includes a T‑BERD/MTS‑8000 platform with the PMD analyzer and a T‑BERD/MTS‑6000 platform with the broadband source module.
A PC‑based Windows application creates customizable, professional dispersion reports with OTDR, CD, PMD, and attenuation data.
