This document introduces the features and characteristics of TI POWER Management Isolated and Non-Isolated Converter Solutions products
The document presents a high‑level overview of Texas Instruments’ power‑management portfolio, covering both isolated and non‑isolated converter families. It outlines product highlights, key features, and the software tools available for design and simulation.
Specific converter families such as the PTH series plug‑in modules, TPS62k and TPS40k families, and the bq2410x/bq2411x Li‑ion chargers are described with their input ranges, output capabilities, and integrated features. Design resources like the SWIFT Designer and Power Landing Page Designer software are also listed.
| Input voltage range (bq2410x/bq2411x) | 3.5 V – 16 V |
|---|---|
| PWM frequency (integrated charger) | 1.1 MHz |
| Maximum charge current (integrated charger) | 2 A |
| Adjustable output voltage (PS62110) | 1.2 V – 16 V |
It supports an input voltage from 3.5 V to 16 V.
The charger operates at a 1.1 MHz PWM frequency.
The charger can deliver up to 2 A of charge current.
Texas Instruments offers the SWIFT Designer and Power Landing Page Designer software for designing DC/DC converters.
