This document introduces the features of the DAC856x, DAC816x and DAC756x series products produced by TI company, including relative accuracy, output range, power supply voltage, reference voltage, input data format, working mode, interface, peripheral circuit, etc.
The document provides detailed specifications for the DAC856x, DAC816x, and DAC756x families, including electrical characteristics, pin configurations, timing diagrams, and typical performance graphs. It also contains handling warnings, absolute maximum ratings, and recommended PCB layout information.
These low‑power, buffered voltage‑output DACs feature an internal 2.5 V reference, 20 mA source/sink capability, and operate over a 2.7 V to 5.5 V supply range, making them suitable for portable and battery‑operated equipment.
The DAC856x family provides 16‑bit resolution.
