The FC98-NX series is a box-type industrial computer from NEC, with features of small size, easy operation, strong scalability and support for dual displays.
The FC98‑NX series is a compact, fan‑less factory computer designed for embedded use. It features a front‑access layout for easy maintenance, dual analog and digital RGB outputs, and optional fan for high‑temperature environments.
Key specifications include a 240 × 280 × 110 mm chassis, two short PCI slots, dual LAN ports (1000BASE‑T/100BASE‑TX), four USB 2.0 ports, and support for Windows 2000, Windows XP and Linux operating systems. This manual is written in Japanese.
| Dimensions (W×D×H) | 240 mm × 280 mm × 110 mm |
|---|---|
| Power consumption (typical) | ≈ 43 W (max ≈ 123 W) |
| PCI slots | 2 short‑size PCI slots (standard) |
| LAN interfaces | 2 ch (1000BASE‑T and 100BASE‑TX) |
| USB ports | 4 × USB 2.0 (standard) |
| Dual‑display outputs | Analog RGB and Digital RGB connectors (standard) |
| Input voltage | AC 700 V – 240 V (±10 % – 15 %) |
The chassis measures 240 mm wide, 280 mm deep and 110 mm high.
It comes with two short‑size PCI slots as standard.
Yes, it includes both analog and digital RGB output connectors for dual‑display operation.
Supported OSes are Windows 2000, Windows XP Professional and Linux (pre‑installed models).
