This document contains the technical parameters, performance parameters, nomenclature, compressor configuration, compressor wiring diagram, electrical code description, compressor application guide and other information of 2SKW-0750 semi-hermetic piston compressor
The document presents the full technical data of the Emerson 2SKW-0750 semi‑hermetic reciprocating compressor, including dimensions, electrical requirements, weight, and performance parameters. It also contains a nameplate example, compressor configuration options, and a wiring diagram for proper installation.
Additional sections cover application guidelines, recommended cooling fan placement, oil charging details, and contact information for Emerson service centers. The information is intended for engineers and technicians responsible for specifying, installing, and maintaining the compressor in refrigeration systems. This manual is written in Chinese.
| Length | 560 mm |
|---|---|
| Width | 330 mm |
| Height (without fan) | 395 mm |
| Net Weight | 92 kg |
| Gross Weight | 97 kg |
| Discharge Port | 7/8" |
| Suction Port | 11/8" |
| Supply Voltage | 380‑420 V, 3‑phase, 50 Hz |
The compressor measures 560 mm in length, 330 mm in width, and 395 mm in height (without fan).
The net weight is 92 kg.
The discharge port is 7/8" and the suction port is 11/8".
