This manual introduces the function and usage methods of DVP06XA-E2 mixed analog input/output module.
The DVP06XA-E2 is a mixed analog input/output module that accepts four analog input signals (voltage or current) and provides two analog output signals. It converts analog signals to 16‑bit digital data for the Delta PLC and can be accessed via FROM/TO instructions or MOV commands.
This manual provides electrical specifications, installation and wiring instructions, control register descriptions, and procedures for adjusting A/D and D/A conversion curves. It also outlines safety precautions, environmental limits, and module connection limits for up to eight modules on a DVP‑PLC MPU.
| Power supply voltage | 24VDC (20.4VDC ~ 28.8VDC) (-15% ~ +20%) |
|---|---|
| Maximum rated power consumption | 2.5W |
| Analog input channels | 4 channels per module |
| Analog output channels | 2 channels per module |
| Analog input voltage range | ±10V, ±5V, ±20mA |
| Analog output voltage range | -10V ~ 10V |
| Maximum output current | 5mA |
| Hardware resolution | 14 bits |
| Input impedance | ≥1MΩ |
| Isolation voltage | 500VDC between digital circuits and ground |
| Response time per channel | 400 µs |
| Operating temperature range | 0 °C ~ 55 °C |
| Maximum modules per PLC | 8 modules |
The module provides four analog input channels per unit.
It requires a 24 VDC supply (20.4 VDC ~ 28.8 VDC).
Up to eight modules can be connected to one MPU.
Each channel responds in about 400 µs.
