HP Integrity NonStop NS16200 server is a top-tier enterprise computing solution designed for absolute data integrity and provides unprecedented application software availability.
The HP Integrity NonStop NS16200 server is designed for high‑availability enterprise workloads, offering linear scalability, fault‑tolerant architecture, and integrated hardware, OS, and database components. It supports up to 64 TB of main memory and over 20 PB of auxiliary storage, targeting mission‑critical applications.
The document lists technical specifications such as Intel 9100 series dual‑core 1.6 GHz processors, up to 16 GB of RAM (32 GB optional), ECC registered DDR2 memory, multiple network interfaces, N+1 redundant power supplies, and physical dimensions of 79 × 45 × 24 in. It also describes system configuration options, chassis variants, and service features. This manual is written in Chinese.
| Processor | Intel 9100 series 1.6 GHz dual‑core |
|---|---|
| Cache | 12 MB |
| Maximum memory | 16 GB (32 GB optional) |
| Memory type | PC2100 ECC registered DDR2 |
| Network I/O ports | 10 – 90 ServerNet ports |
| Power supply | Standard N+1 redundant power supply |
| Weight | 1.200 lb (545 kg) |
| Power consumption | 2.800 VA |
It uses Intel 9100 series dual‑core processors running at 1.6 GHz.
The server supports a minimum of 4 GB and a maximum of 16 GB of memory, with an optional 32 GB configuration.
