The 74AVCM162836 is a 20-bit universal bus driver. Data flow is controlled by output enable (OE), latch enable (LE) and clock inputs (CP).
The 74AVCM162836 is a 20-bit universal bus driver designed for high-speed data flow control. It features inverted register enable and 15 integrated 50-ohm termination resistors to minimize output overshoot and undershoot. Data flow is managed by output enable (OE), latch enable (LE), and clock (CP) inputs.
| Supply Voltage Range | 1.2 V to 3.6 V |
|---|---|
| Number of Bits | 20-bit |
| Termination Resistors | 15 Q termination resistors |
| Package Type | 56-Pin Plastic Thin Shrink Small Outline (TSSOP) |
Data flow is controlled by output enable (OE), latch enable (LE) and clock inputs (CP).
The device operates with a wide supply voltage range of 1.2 V to 3.6 V.
This driver includes 15 Q termination resistors to minimize output overshoot and undershoot.
