Start here
Yamaha GA32/12 and GA24/12 User Manual
This manual explains safety precautions, proper handling, and maintenance for the GA32/12 and GA24/12 mixing consoles. It covers power requirements, environmental restrictions, and steps to take in case of abnormal operation such as smoke, unusual sounds, or water intrusion.
The document also describes the front‑panel layout, input and output sections, and the GA Diversity function. Detailed information is given for mono and stereo input channels, gain controls, EQ sections, mix buses, matrix outputs, talk‑back routing, and monitoring options. This manual is written in Japanese.
Yamaha GA32 specifications
| Total harmonic distortion (THD) | < 0.1 % @20 Hz‑20 kHz |
|---|---|
| Signal‑to‑noise ratio | 68 dB |
| Power consumption | 120 W |
| Dimensions (GA32/12) | 1372 mm × 161 mm × 705 mm (W × H × D) |
| Weight (GA32/12) | 38 kg |
| Input sensitivity (CH INPUT 1‑12) | -86 dB (8.8 mV) |
| Maximum output level (MIX OUT) | +24 dB (12.3 V) |
All Yamaha GA32 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What gain range can be set on the console?
The gain can be adjusted from 10 dB up to 34 dB.
How many EQ bands are available and what are they?
The console includes four EQ bands: HIGH, HI‑MID, LO‑MID, and LOW.
