Key facts
- Brand
- VICOR
- Model
- 150WATTS
- Industry
- Industrial
- Documents
- 2
- Languages
- EN
- Last added
- 2012-06-08
Start here
VICOR 48Vin 24Vout 150Watts DC-DC Converter Module Model Number V48C24C150B * handbook
The V48C24C150B is a 48 Vin / 24 Vout DC‑DC converter module delivering up to 150 W. It is intended for telecommunications and distributed power systems and features a low‑noise ZCS/ZVS architecture with parallelable operation and N+M fault tolerance.
Key specifications include a 36‑75 V input range, 24 V regulated output, 88.5 % efficiency at full load, 2000 Vrms isolation (in‑to‑out), and a compact size of 2.28 × 1.45 × 0.5 in. The manual details electrical characteristics, control pins (PC, SC, PR), mechanical drawings, and pin‑style options for board mounting.
VICOR 150WATTS specifications
| Input Voltage Range | 250 to 425 Vdc |
|---|---|
| Output Voltage | 48V (Nominal) |
| Maximum Output Power | 150 Watts |
| Efficiency | 86.3% |
| Maximum Operating Temperature | 100°C at full load |
| Isolation Voltage (Input to Output) | 3000 Vrms |
Source: VICOR 375Vin 48Vout 150Watts DC-DC Converter Module Model Number V375C48C150B
All VICOR 150WATTS documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the input surge withstand rating?
The module can withstand an input surge of 500V for less than 100ms.
From: VICOR 375Vin 48Vout 150Watts DC-DC Converter Module Model Number V375C48C150B
What is the output voltage programming range?
The output voltage can be programmed from 10% to 110% of the nominal value.
From: VICOR 375Vin 48Vout 150Watts DC-DC Converter Module Model Number V375C48C150B
What input voltage range does the V48C24C150B accept?
The module operates with an input voltage from 36 V to 75 V.
From: VICOR 48Vin 24Vout 150Watts DC-DC Converter Module Model Number V48C24C150B * handbook
What is the maximum output power of the converter?
It can deliver up to 150 W of output power.
From: VICOR 48Vin 24Vout 150Watts DC-DC Converter Module Model Number V48C24C150B * handbook
