UNI‑T UT305/UT306 Series User Manual
The UNI‑T UT305/UT306 series are non‑contact infrared thermometers that measure surface temperature by detecting emitted infrared energy. The manual provides an introduction, safety precautions, key features, display information, button and interface descriptions, and detailed operating instructions.
Safety warnings include laser eye protection, avoiding explosive atmospheres, and proper handling of the device. Power options are a 9 V battery or USB, and the instrument offers adjustable emissivity, dual‑color backlit display, and various temperature read‑outs (current, min, max, average, delta). This manual is written in Chinese.
UNI-T UT306 specifications
| Bandwidth | 60 MHz |
|---|---|
| Rise Time | 5.8 ns |
| Sample Rate | 0SOMS/s ~ 1GS/s |
| Vertical Sensitivity | 2mV ~ SVidiv |
| Record Length (Max) | 1M |
| Trigger Type | Edge, Pulse, Video and Alternate |
| Standard Ports | USB Device, USB Host, RS‑232C (optional LAN, GPIB) |
| Mathematics Functions | Add, Subtract, Divide, Reverse, FFT |
| Display | 64k, Full colour LCD, 320 × 240 |
| Power Input | 100‑240 VAC RMS, 45‑440 Hz, CAT II |
| LCD Diagonal | 145 mm (5.7 inches) |
| Net Weight | 4.9 kg (excluding packaging) |
| Product Dimensions | 320 mm × 150 mm × 292 mm |
Source: UNI-T UT3062C Digital Storage Oscilloscope Product Manual
All UNI-T UT306 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the bandwidth of the UNI‑T UT3062C oscilloscope?
The bandwidth is 60 MHz.
From: UNI-T UT3062C Digital Storage Oscilloscope Product Manual
What standard ports are available on the UT3062C?
It includes USB Device, USB Host, RS‑232C, and optional LAN and GPIB ports.
From: UNI-T UT3062C Digital Storage Oscilloscope Product Manual
How does the device indicate a low‑battery condition?
When the battery voltage drops to about 4.5 V, a low‑battery symbol appears on the display.
