UNI-T Manuals

ManualLib has 30 UNI-T manuals covering 4 models. The most documented models are 400MV, UT804, UT602. Every file can be read online or downloaded as a PDF for free.

User Manual 14

Key facts

Manuals
30
Models
4
Languages
ZH · JA
Last added
2026-09-30

UNI-T models by category

Temperature sensors 1
UT306
Other 3
400MVUT804UT602

Latest UNI-T manuals

  • UNI‑T UPO2000CS Series Digital Phosphor Oscilloscope User Manual

    User Manual 74 pages · 2.2 MB · ZH

    Official user manual for the UNI‑T UPO2000CS series digital phosphor oscilloscope, covering operation, safety, specifications and maintenance.

  • UNI‑T UT3200 Series Multi‑Channel Temperature Meter User Manual

    User Manual 36 pages · 9.2 MB · ZH

    User manual for UNI‑T UT3200 series temperature meters covering safety, setup, operation and specifications.

  • UNI-T UT2152C DATA SHEET

    UT2152C is a digital storage oscilloscope from Uni-Trend. It has a bandwidth of 150MHz, a rise time of 2.3ns, a sample range of 500MS/s to 1GS/s, a vertical sensitivity of 2mV to 5V/div, a record length of 1M (max), a real-time sampling rate of 500MS/s to 1GS/s, equivalent to 25GS/s scan time base, 2ns to 50s/div trigger type, edge, pulse, video and alternate automatic waveform measurements 28 ports, standard: USB device, USB host and RS-232C, optional: LAN mathematics add, subtract, divide, reverse and FFT applications College education, R&D, electronic product assembly line, industrial control, etc.

  • UNI-T UT15C

    UT15C is a multifunctional voltage meter produced by Shanghai Yulite. It has the functions of measuring direct current voltage, alternating current voltage, resistance, etc. This product adopts precision high-quality components, high accuracy and good stability, and is an ideal choice for electrician maintenance, equipment testing, and school laboratories.

  • UNI-T UT2062C Digital Storage Oscilloscope Product Manual

    The UT2062C Digital Storage Oscilloscope features a bandwidth of 60 MHz, rise time of ≤5.8 ns, sample range of 500MS/s ~ 1GS/s (UT2025 series is 250MS/s), vertical sensitivity of 2mV ~ 5V/div, maximum record length of 1M, real-time sample rate of 500MS/s ~ 1GS/s, equivalent to 25GS/s, scan time base of 10ns ~ 50s/div, trigger types include edge, pulse, video, and alternate, automatic waveform measurements with 28 ports, standard ports include USB Device, USB Host (not available in UT2025 series), RS-232C, optional LAN, mathematics functions include add, subtract, divide, reverse, and FFT, suitable for college education, R&D, electronic product assembly line, industrial control, etc.

  • UNI-T - Basic Functions Range Best Accuracy DC Voltage 400mV/4V/40V/400V/600V ±(0.8% 1) AC Voltage 400mV/4 Manual

    This is a detailed information table of a multimeter, including basic functions, ranges, accuracy, special functions, etc.

  • UNI-T - UT2202C Digital Storage Oscilloscope Product Enlarge SPECIFICATIONS Feature UT2202C Manual

    The UT2202C Digital Storage Oscilloscope is the second generation product of the UT2202 series. It adopts advanced technology and process, has higher sampling rate, wider bandwidth, higher performance and more affordable price. It is an ideal choice for engineers and technicians.

  • UNI-T - Basic Functions Range Best Accuracy DC Voltage 400mV/4V/40V/400V/1000V ±(0.8% 8) AC Voltage 4V/40V/4

    The document introduces a digital multimeter with basic functions and the best accuracy in its range, including DC voltage, AC voltage, DC current, AC current, resistance, capacitance, frequency, etc. The product features high accuracy, multiple functions, and portability.

  • UNI-T UT2025B Manual

    UT2025B Digital Storage Oscilloscope Product Specifications: Bandwidth 25 MHz, Rise Time ≤14 ns, Sample Range 500MS/s ~ 1GS/s (UT2025 series is 250MS/s), Vertical Sensitivity 2mV ~ 5V/div, Record Length (Max) 1M Sample Rate Real time 500MS/s ~ 1GS/s, Equivalent: 25GS/s, Scan Time Base 20ns ~ 50s/div, Trigger Type Edge, Pulse, Video and Alternate, Automatic Waveform Measurements 28, Ports Standard: USB Device, USB Host (UT2025 series don't have this function); RS-232C, Optional: LAN, Mathematics Add, Subtract, Divide, Reverse and FFT, Applications College Education, R&D, Electronic product assemble line, Industrial Control etc., Display Monochrome LCD, 320 x 240

  • UNI-T UT3062C Digital Storage Oscilloscope Product Manual

    The UT3062C Digital Storage Oscilloscope features a bandwidth of 60 MHz, rise time of ≤5.8 ns, sample range of 500MS/s ~ 1GS/s (250MS/s for UT3025 series), vertical sensitivity of 2mV ~ 5V/div, maximum record length of 1M samples, real-time sample rate of 500MS/s ~ 1GS/s (equivalent to 25GS/s), scan time base of 5ns ~ 50s/div, trigger types including edge, pulse, video, and alternate, automatic waveform measurements with 28 ports, standard ports include USB Device, USB Host (not available in UT3025 series), RS-232C, optional ports include LAN and GPIB, mathematical functions include add, subtract, divide, reverse, and FFT, suitable for college education, R&D, electronic product assembly line, industrial control, etc., equipped with a 64k full-color LCD display with a resolution of 320 x 240.

  • UNI-T UT2102C Digital Storage Oscilloscope Product

    UT2102C is a digital storage oscilloscope from Uni-Trend. It has a bandwidth of 100MHz, a rise time of ≤3.5ns, a sample range of 500MS/s ~ 1GS/s, a vertical sensitivity of 2mV ~ 5V/div, a record length (maximum) of 1M, a sample rate of real time 500MS/s ~ 1GS/s, equivalent to 25GS/s, a scan time base of 5ns ~ 50s/div, a trigger type of edge, pulse, video and alternate, automatic waveform measurements of 28 ports, standard of USB device, USB host and RS-232C, optional of LAN, mathematics of add, subtract, divide, reverse and FFT, and applications of college education, R&D, electronic product assembly line, industrial control, etc.

  • UNI-T - Basic Functions Range 500V: 0.1M

    This document introduces a basic function tester with a range of 500V and 1000V, including functions such as DC voltage, AC voltage, DC current, AC current, resistance, capacitance, frequency, etc. The product features auto ranging, diode testing, continuity buzzer, true RMS, data hold, data logging, etc. The product comes in red and grey color, weighs 505g, and has dimensions of 97×202×46mm.

  • UNI-T UT581/582 equipment Manual

    This manual introduces the features of UT581/582 products, including safety tips, characteristics, technical specifications, instrument appearance and accessories, measurement methods, maintenance and repair, etc.

  • UNI‑T UT200C/D User Manual

    User Manual 2 pages · 3.4 MB · ZH

    The UNI‑T UT200C/D multimeter user manual provides safety guidelines, operation instructions, specifications and maintenance procedures.

  • UNI‑T UT136A/B/C/D Hand‑held Digital Multimeter User Manual

    User Manual 2 pages · 10.9 MB · ZH

    Operating instructions and safety guidelines for the UNI‑T UT136 series hand‑held digital multimeter.

Which document do I need?

User Manual

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Questions answered in UNI-T manuals

What is the warranty period for the UPO2000CS series?

The warranty is three years from the date of purchase from UNI‑T or an authorized distributor.

From: UNI‑T UPO2000CS Series Digital Phosphor Oscilloscope User Manual

What is the recommended operating temperature range?

The instrument operates from 0 °C to +40 °C; non‑operating storage range is –20 °C to +60 °C.

From: UNI‑T UPO2000CS Series Digital Phosphor Oscilloscope User Manual

What temperature range does the UT3200 series measure?

It measures from –200 °C up to 1800 °C.

From: UNI‑T UT3200 Series Multi‑Channel Temperature Meter User Manual

What are the physical dimensions of the device?

The instrument measures 340 mm × 214 mm × 89 mm (L × W × H).

From: UNI‑T UT3200 Series Multi‑Channel Temperature Meter User Manual

How do I replace the battery?

Remove the screws, take out the old 6F22 battery, insert a new 6F22 battery with the correct polarity, and reinstall the screws.

From: UNI‑T UT200C/D User Manual

What is the automatic shut‑off time?

The instrument powers off automatically after about 8‑10 minutes of no key activity.

From: UNI‑T UT200C/D User Manual
