Symbol PPT 8800 Quick User Guide
The Symbol PPT 8800 is a Pocket PC handheld device designed for mobile data capture. This quick guide provides essential information on configuring the unit, using the Windows Mobile software, and accessing basic functions.
The document also includes warranty terms, spare‑part policies, repair procedures, and contact details for technical support and regional distributors worldwide.
Symbol PPT 8800 specifications
| Dimensions | 1.3 in × 3.1 in × 5.7 in |
|---|---|
| Weight | 300 g |
| Battery capacity | 1700 mAh (3.7 V) rechargeable |
| Processor | Intel XScale PXA250 |
| Operating system | Microsoft Windows CE 4.1 |
| RAM / ROM | 32 MB RAM / 32 MB ROM |
| RS‑232 speed range | 1200 bps – 115.2 kbps |
| IrDA speed | up to 115.2 kbps (SIR) |
| Operating temperature | -10 °C to +50 °C |
| Relative humidity range | 5 % – 90 % RH |
All Symbol PPT 8800 documents by type
The shortest path to a working setup, usually only a few pages.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the warranty period for Symbol PPT 8800 hardware?
Hardware products are warranted for twelve (12) months from the date of shipment, provided the product remains unmodified and is used under normal conditions.
What barcode symbologies does the device support?
It supports UPC/EAN/JAN, Code 39, Code 93, Code 128, Interleaved 2‑of‑5, Discrete 2‑of‑5, NW‑7 and UCC/EAN‑128.
What are the operating temperature limits of the collector?
The device can operate from –10 °C up to +50 °C.
What wireless technologies does the PPT 8800 support?
The device supports Spectrum24 and Bluetooth wireless connections.
What frequency bands are used for FCC RF compliance?
The PPT 8800 operates in the 2.400‑2.4835 GHz band with EIRP limits of 100 mW (EEA) or 10 mW (other regions).
