Key facts
- Brand
- Rexroth
- Model
- TU1
- Category
- Industrial Supply
- Documents
- 2
- Languages
- EN
- Last added
- 2012-02-23
Start here
Bosch Rexroth TU1 Plastic Soft Tube User Guide
User Manual 11 pages · 1.3 MB · EN
This guide presents the technical data for the Bosch Rexroth TU1 plastic soft tube series, covering variants such as TU1‑R, TU1‑S, TU1‑X and TU1‑F. It includes pressure ratings, temperature limits, tube dimensions and mass per length for each size.
The document also provides contact information for Bosch Rexroth Pneumatics, including phone numbers, fax, email and web address, and contains legal notices about the data and its usage.
Rexroth TU1 specifications
| Pressure range | -0.95 bar to +10 bar |
|---|---|
| Operating temperature | 20 °C to 480 °C |
| Tube size example | O3‑16 mm |
All Rexroth TU1 documents by type
User Manual 1
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Product Leaflet 1
Questions answered in these manuals
What is the pressure range for the TU1 plastic soft tubes?
The tubes are rated from –0.95 bar up to +10 bar.
What temperature range can the TU1 tubes operate in?
They can be used from 20 °C up to 480 °C.
What is the pressure range for the TU1‑S cylinder?
The TU1‑S cylinder is rated for pressures from 10 to 26 bar.
