Bosch Rexroth TC08 Valve System Manual
The Bosch Rexroft TC08 valve system manual provides detailed technical data, connection types and installation guidelines for the TC08 series. It includes pressure ranges, temperature limits, electrical supply options and dimensional information.
The document also lists part numbers, contact information for Bosch Rexroth offices in China and Germany, and legal notices about the use of the data. It is intended for engineers and technicians who install, operate or service the TC08 valve system. This manual is written in Japanese.
Rexroth TC08 specifications
| Maximum working pressure | 800 bar |
|---|---|
| Operating pressure range | -0.9 bar to 10 bar |
| Control pressure range | 2.5 bar to 10 bar |
| Operating temperature range | -109 °C to +505 °C |
| Electrical supply (DC) | 24 V |
| Electrical supply (AC) | 230 V / 110 V / 24 V |
| Ingress protection | IP65 |
All Rexroth TC08 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the maximum working pressure of the TC08 valve system?
The TC08 valve system is rated for a maximum working pressure of 800 bar.
What are the operating temperature limits?
The system can operate from –109 °C up to +505 °C.
