Start here
Lenovo R630 G6 / TR650 G6 User Manual
This manual covers safety warnings, ESD protection, power handling, and environmental requirements for Lenovo's WanQuan R630 G6 and TR650 G6 servers. It explains how to safely disconnect power, avoid static discharge, and ensure proper ventilation before operating the system.
The guide also details the hardware specifications, including CPU sockets, memory capacity, power supply options, expansion slots, and physical dimensions. Installation steps, rack mounting, and recommended UPS usage are described to help technicians set up and maintain the servers reliably. This manual is written in Chinese.
Lenovo TR650 specifications
| CPU sockets | 4 |
|---|---|
| Maximum memory | 32 GB |
| Input voltage range | 200~240 V / 50‑60 Hz |
| Maximum hot‑swap SCSI drives (R630 G6) | 5 |
| Maximum hot‑swap SCSI drives (TR650 G6) | 10 |
| System dimensions (R630 G6) | 172.7 mm × 444.53 mm × 698.5 mm |
| Maximum system weight (R630 G6) | 40 kg |
All Lenovo TR650 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What input voltage range should be used for the server?
The server is designed for an input voltage of 180 V to 260 V.
How many hot‑swap SCSI drives can the R630 G6 support?
The R630 G6 can accommodate up to five hot‑swap SCSI drives.
How many CPU sockets does the ThinkServer R630 G6 support?
The server provides four CPU sockets.
From: Lenovo ThinkServer R630 G6 / TR650 G6 Server User Manual
What is the maximum memory the server can hold?
It can support up to 32 GB of ECC Registered DDR‑I 400 SDRAM memory.
From: Lenovo ThinkServer R630 G6 / TR650 G6 Server User Manual
