Allied Telesis SwitchBlade x908 Manuals

ManualLib has 5 documents for the Allied Telesis SwitchBlade x908 (Network Switches): 1 user manual, 2 installation guides, 2 product leaflets. Every file can be read online or downloaded as a PDF for free.

User Manual 1Installation Guide 2Product Leaflet 2

Key facts

Model
SwitchBlade x908
Documents
5
Languages
EN
Last added
2023-10-17

Start here

Allied Telesis SwitchBlade x8100 Series Switches OSPF Configuration Guide

Allied Telesis SwitchBlade x8100 Series Switches OSPF Configuration Guide

User Manual 24 pages · 696 KB · EN

This guide explains how to configure OSPF routing on Allied Telesis switches running AlliedWare Plus OS. It covers entering OSPF configuration mode, defining active IP interfaces, redistributing routes, adjusting metrics, and filtering routes. The guide uses a sample network diagram to illustrate configurations and includes full configuration scripts for all devices in the example network.

The document is targeted at network administrators and engineers who need to set up OSPF on Allied Telesis switches. It assumes familiarity with basic networking concepts and the AlliedWare Plus OS command-line interface.

Read online

Allied Telesis SwitchBlade x908 specifications

Height44.5 mm (+5.1 mm with rubber feet)
Width440 mm
Depth440 mm
Weight≤ 7.3 kg (unpackaged)
Operating Temperature Range0 °C to 50 °C

Source: Allied Telesis x900 Series Switch and SwitchBlade x908 Hardware Reference Manual

All Allied Telesis SwitchBlade x908 documents by type

User Manual 1

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Questions answered in these manuals

What is the default metric for redistributed routes in OSPF?

The default metric for redistributed routes (from sources other than BGP) is 20.

From: Allied Telesis SwitchBlade x8100 Series Switches OSPF Configuration Guide

How do you configure OSPF on a switch?

Enter OSPF configuration mode with 'configure terminal router ospf 1'.

From: Allied Telesis SwitchBlade x8100 Series Switches OSPF Configuration Guide

What models are covered in this Installation and Safety Guide?

The guide covers AT-8948, x900-12XT/S, x900-48FE, AT-9924Ts, x900-48FE-N, x900-48FS, AT-9924T, AT-9924SP, x900-24XT, x900-24XT-N, x900-24XS, and SwitchBlade® x908.

From: Allied Telesis x900 Series Switch and SwitchBlade® x908 Installation and Safety Guide

What is the maximum ambient temperature for AT-8948 and x900-48FE models?

The maximum ambient temperature is 50°C (122°F).

From: Allied Telesis x900 Series Switch and SwitchBlade® x908 Installation and Safety Guide

What is the required minimum core size for the supply cable?

The supply cable must have a minimum core size of 3.3mm2 (12 AWG) high strand count copper wire.

From: Allied Telesis x900 Series Switch and SwitchBlade® x908 Installation and Safety Guide

How much bare conductor must be exposed when stripping the supply cable wires?

You must strip the wires to expose 7.5mm (0.31in.) of bare conductor.

From: Allied Telesis x900 Series Switch and SwitchBlade® x908 Installation and Safety Guide
