The Sony SRG-301SE user manual provides safety rules, component descriptions, connection methods, installation steps, and full specifications for the HD…
This manual introduces the Sony SRG-301SE high‑definition video camera, covering safety guidelines, the location and function of each part, and how to connect the device to power, network, and external equipment. It also explains how to configure the camera via a web browser and the Sony Network Camera toolbox.
Detailed installation instructions are provided for desk, tripod, and ceiling‑mount setups, followed by a complete list of technical specifications such as video formats, lens details, power requirements, and environmental limits. This manual is written in Chinese.
| Video resolution | 1920×1080p/59.94 (A)/(B) |
|---|---|
| Lens type | 1/2.8型 Exmor CMOS, 20× optical / 12× digital |
| Minimum illumination | 1.4 lux (F1.6, 30 fps, low‑sensitivity off) |
| Power consumption | 16.8 W |
| Dimensions (W×H×D) | 157 × 164 × 163 mm |
| Weight | ≈1.4 kg |
Yes. Attach the supplied ceiling brackets (A and B) with the M3×8 screws and steel cable, ensuring the mounting angle is within ±15°.
