The sample presents technical features, modules, installation guidance, communication options, and ordering data for the Siemens S7-1200 programmable…
The SIMATIC S7-1200 series is a compact, modular programmable controller family that integrates a PROFINET interface, powerful process functions and flexible expandability for small‑to‑medium automation tasks. It offers a range of CPU modules, signal and I/O extension modules, and communication options that can be mixed to suit specific applications.
The document details hardware dimensions, environmental limits, EMC compliance, memory capacities, high‑speed counter capabilities, and provides ordering numbers for each module. It also lists supported communication protocols such as PROFINET, PROFIBUS, Modbus RTU, GPRS and USS, and references the TIA engineering software platform for configuration and programming. This manual is written in Chinese.
| CPU module width (1211C/1212C) | 90 mm |
|---|---|
| CPU module width (1214C) | 110 mm |
| Shared work memory | 50 KB |
| PROFINET data rate | 10/100 Mbit/s |
| High‑speed counters | 6 total (3 × 100 kHz, 3 × 30 kHz) |
It supports up to six high‑speed counters: three at 100 kHz and three at 30 kHz.
