This guide covers installation, wiring, control board connections, power board details, software setup, and status codes for the CDHD2 servo drive series.
The document serves as a quick start guide for the CDHD2 servo drive series. It provides an overview of different models based on communication protocols such as RS232, CANopen, and EtherCAT, along with essential safety warnings regarding high voltage and grounding requirements.
The manual details the step-by-step installation process, including system wiring diagrams for various input voltages (MV and LV), connections for motor feedback, braking systems, and digital I/Os. It also includes specific information on cable part numbers, software installation via ServoStudio, and a comprehensive list of operational status, warning, and fault codes. This manual is written in Chinese.
No, the drive does not have enough current to activate motor brakes and requires an external relay controlled by a digital output.
An external power supply of 24V is required to operate the motor brake relay.
The maximum length for the C8 daisy chain cable is 0.5 meters.
The RS232 cable must have a shielding coverage of at least 85 percent copper braid.
